Cold Crucible Vacuum Induction Suspension Smelting Furnace

Cold Crucible Vacuum Induction Suspension Smelting Furnace

Suspension smelting is the production process of smelting and casting metal in a water-cooled copper crucible under a vacuum or in a protective atmosphere. When the induction coil is energized, a strong magnetic field can be formed inside the cold crucible to make the molten metal liquid be in semi-suspension or full-suspension state.

Inquire Now Next Product

Product Details

Widely used in smelting purification of titanium, zirconium, nickel, copper and other materials, titanium alloy smelting and centrifugal casting; can also be used for melting purification of rare earth materials, refractory metals, semiconductor materials, radioactive materials.
Cold Crucible Vacuum Induction Suspension Smelting Furnace

Product Features and Special Configuration

Equipment’s main technical indicators:

Intermediate frequency power: 50KW-800KW

All stainless steel furnace body, usually vertical front door structure

High purity copper forging petal crucible, long service lifeI

GBT high-frequency induction power supply, good frequency matching

Online feeding mechanism for a variety of shapes to add alloy material

Centrifugal Casting / Cold Casting / Investment Casting A variety of casting options

According to the smelting capacity and the characteristics of the melting material to choose different vacuum unit

Replaceable ceramic crucible to achieve common vacuum induction melting

Security and alarm system to ensure the safety of equipment

PC / PLC automatic / manual control system
