Silicon Carbide Reaction Sintering Furnace is mainly applied to silicon carbide reaction sintering and silicon nitride sintering process.
Mainly used in the production of silicon carbide ceramic roll bar, beam, desulfurization nozzle, nozzle, cold duct, shed, sagger, heat pipe, radiation tube and outer tube, nozzle, bushings, seals and the High-temperature, wear-resistant, corrosion-resistant silicon carbide ceramic special-shaped pieces, products with its high strength, high hardness, abrasion resistance, high temperature resistance, corrosion resistance, oxidation resistance, thermal shock resistance and thermal conductivity, Heat and high temperature creep and other excellent performance, are widely used in military, aerospace, nuclear power, LCD and health and building ceramics, metallurgy, chemical, machinery, automotive, papermaking, medicine and other fields.
Technical Parameters
| Model | Average temperature zone size(mm) | The highest temperature（℃） | Ultimate vacuum（Pa） | Temperature uniformity（℃） | Rate of pressure rise（Pa/h）≤0.4 | Loading capacity（Kg） |
| VHS225 | 200*200*500 | 1800 | 3.0*10-1 | ±5 | ≤0.5 | 80 |
| VHS337 | 300*300*700 | 1800 | 3.0*10-1 | ±5 | ≤0.5 | 120 |
| VHS449 | 400*400*900 | 1800 | 3.0*10-1 | ±5 | ≤0.5 | 200 |
| VHS6620 | 600*600*2000 | 1800 | 3.0*10-1 | ±5 | ≤0.4 | 600 |
| VHS6625 | 600*600*2500 | 1800 | 3.0*10-1 | ±5 | ≤0.4 | 800 |
| VHS6630 | 600*600*3000 | 1800 | 3.0*10-1 | ±5 | ≤0.4 | 1000 |
| VHS7740 | 700*700*4000 | 1800 | 3.0*10-1 | ±5 | ≤0.4 | 1200 |
| VHS7745 | 700*700*4500 | 1800 | 3.0*10-1 | ±5 | ≤0.4 | 1500 |
| VHS7750 | 700*700*5000 | 1800 | 3.0*10-1 | ±5 | ≤0.4 | 1800 |
(We can customize your own vacuum sintering furnace according to your special needs)
SILICON CARBIDE REACTION SINTERING FURNACE
Product Features and Special Configuration
Equipment technical characteristics:
The sintering furnace adopts special hot zone structure and heating element design to ensure good temperature uniformity.
The use of a special design of the plastic drainage system, which can effectively prevent contamination of internal components, to extend the heating device life cycle;
Equipped with vacuum sintering and partial pressure sintering function;
The furnace is equipped with temperature, pressure, water pressure, vacuum and other interlocking features, with a highly secure protection and prevention functions;
with remote control operation, remote fault diagnosis and remote program updates and other functions;
Optional configuration:
Furnace: all-carbon steel/ inner stainless steel / all stainless steel;
Vacuum pump: foreign brands / Chinese brands;
Operation panel: touch screen / industrial computer;
Temperature controller: SHIMADEN / EUROTHERM;
Efficient debinding/dusting device (with a new structure of air intake system).
Advanced, fast and maintenance-free rapid cooling structure. (avoiding the drawbacks of old-fashioned structures with low efficiency and easy water leakage)
A variety of temperature measurement methods (K, WRe and other thermocouples, infrared thermometers) or a combination of choices.
VHS7740 and above vacuum furnace adopts a new square structure with four-way heating, which achieves small maintenance and remarkable energy-saving effect; and is equipped with a special hydraulic forklift loading and unloading system;
For the special nature of the silicon carbide grinding cylinder, our company can customize the vertical silicon carbide reaction sintering furnace; if necessary, you can consult by telephone;
