The annealing furnace changes the crystal structure, refines the structure, eliminates stress and softens the material to the metal material and the workpiece, and vacuum annealing can prevent oxidative decarburization, degassing and degreasing, and evaporation of the oxide to improve the surface brightness and mechanical properties of the workpiece.
Mainly suitable for deep-drawn stainless steel parts, such as plumbing equipment, water expansion parts, pins, medical equipment, stainless steel nails, stainless steel stranded wire, riveted parts, stainless steel bearings, case, strap, tool, micro shaft, self-drilling, self-drilling A multi-purpose furnace for continuous bright annealing, solid solution, demagnetization and stainless steel quenching treatments, such as tableware under the control of a protective atmosphere. After treatment, the product has a smooth surface, no oxidation and no decarburization. It has the advantages of high production efficiency, low energy consumption, less pollution, convenient operation and low labor intensity. It can also be used for brazing and sintering of metal materials.
Technical Parameters:
| Model | Inner Size(mm) | Max Temp(℃) | Ultimate Vacuum(Pa) | Temp Uniformity(℃) | Leak Rate Pa*L/S | Loading Capacity（Kg） |
| VAF-016 | 200*200*500 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 30 |
| VAF-028 | 300*300*400 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 80 |
| VAF-075 | 400*400*600 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 200 |
| VAF-140 | 500*500*700 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 350 |
| VAF-250 | 600 * 600 * 900 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 500 |
| VAF-460 | 700*700*1200 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 700 |
| VAF-750 | 800*800*1500 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 1000 |
| VAF-3500 | 800*800*7000 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 4500 |
| VAF-1900 | 700*700*15000 | 1300 | 1.3 x 10-3 | ±5 | 1.0*10﹣6 | 8000 |
| Power Supply:AC 1Ψ 110V;AC 1Ψ 220V;AC 3Ψ 220V;3Ψ380V; 3Ψ400V; 3Ψ480V＋N＋G, 60/50Hz. | ||||||
| The technical information will be subjected to change without notice | ||||||
| Customized Service: Welcome to Non-standard, Special requirements, OEM/ODM orders. | ||||||
ADVANTAGES
1, The furnace has interlocking functions such as temperature, pressure, water pressure and vacuum, and has high safety protection and protection functions.
2, The appearance of the furnace shell is straight and beautiful. The electric heating elements outside the furnace shell are concentrated and distributed, and a protective cover is provided
3, Product welds are even and smooth, no voids, inclusions and fusion defects
4, Remote control operations, remote troubleshooting and remote program updates
PRODUCT PROPERTIES
We can customize your own vacuum annealing furnace according to your special needs.
Product:Case, strap, tool, micro shaft, etc.
Effective heating zone:Minimum 200*200*500; maximum 700*700*15000 (can be customized)
Operating temperature:Up to 1300 ° C
Ultimate vacuum:1.3 x 10-3 (Pa)
Pressure rise rate:≤0.67 (Pa/h)
Temperature Controller: GRANDE5600
Structure:The furnace body is a horizontal single-chamber horizontal loading structure
Loading amount:30-8000 (Kg)
Operation panel:Touch screen / industrial computer
Vacuum pump:Foreign brands / Chinese brands
Furnace body:Full carbon steel / inner stainless steel / all stainless steel;
Insulation:All molybdenum/molybdenum plus stainless steel/composite carbon felt padding
VAF VACUUM ANNEALING FURNACEE
Product Features and Special Configuration
This series of horizontal vacuum annealing furnaces are mainly used for vacuum annealing of special materials, stainless steel, selenium steel core, precious metal parts, silver-copper composite rivets and sheet metal parts.
The device is designed for annealing small parts and other vacuum conditions;
The furnace has good sealing performance, effectively avoiding oxidation and rust of the workpiece surface during annealing, and improving processing quality;
The holding furnace body can be moved backwards. After the annealing is completed, the cooling rate is increased while maintaining the vacuum state.
Horizontal vacuum annealing furnace is mainly used for vacuum annealing of special materials, stainless steel, selenium steel core, precious metal parts, silver-copper composite rivets and sheet metal parts.
The device is designed for annealing small parts and other vacuum conditions;
The furnace has good sealing performance, effectively avoiding oxidation and rust of the workpiece surface during annealing, and improving processing quality;
The well vacuum annealing furnace series uses pre-vacuum gas protection.
A hot air circulation device is arranged on the furnace cover to make the atmosphere and temperature in the furnace uniform;
It can be equipped with a vacuum pump to increase the ventilation speed and make the atmosphere more pure;
With protective gas, after annealing, the product has no oxidation, eliminates processing stress, improves the magnetic properties of the iron core, and reduces iron loss;
The furnace temperature control adopts PID automatic power regulation and the temperature control is stable.
The furnace body is a horizontal single-chamber horizontal charging structure, and a built-in vacuum annealing furnace can also be designed;
High temperature molybdenum is tropical or isostatically pressed graphite heating, molybdenum and aluminum silicate insulation fiber felt are insulated, and temperature uniformity is good;
The furnace is equipped with interlocking functions such as temperature, pressure, water pressure and vacuum, and has a high degree of safety protection and prevention functions;Features such as remote control operation, remote troubleshooting and remote program update
